PIPEWELD 8010 PLUS

Cellulosic coated electrode designed for low alloy steel. Deep penetration welding in all positions, especially designed for vertical down welding of high strength pipelines. Provides high economic benefits compared to welding vertical up. Recommended for welding pipe-lines of API 5LX: X60- X70.

Request A Quote

Highlights

Process

Specifications
Classifications	SFA/AWS A5.5 : E8010-P1 EN ISO 2560-A : E 46 2 Z C 21

Welding Current	DC+
Alloy Type	Low alloyed (0.3 % Ni, 0.25 % Mo)
Coating Type	Cellulosic covering

Tensile_Properties
Testing Condition	Yield Strength	Tensile Strength	Elongation
AWS
As Welded	530 MPa	620 MPa	23 %

Charpy Testing
Testing Condition	Testing Temp	Impact Value
AWS
As Welded	-30 °C	40 J

Typical Weld Metal Analysis %
C	Mn	Si	Ni	Cr	Mo
0.09	0.4	0.10	0.4	0.021	0.31

Deposition Data
Diameter	Amps	Volts	Efficiency (Per)	Fusion time per electrode at 90Per I max	Deposition rate at 90Per
3.2 x 350 mm	65-120 A	30 V	62 %	86 sec	0.68 kg/h
4.0 x 350 mm	90-180 A	29 V	68 %	84 sec	1.15 kg/h

Description	Product Number
PIPEWELD 8010 PLUS 3.2x350mm	2P80323B40
PIPEWELD 8010 PLUS 4.0x350mm	2P80403B40
PIPEWELD 8010 PLUS 5.0x350mm	2P80503B40
