Renegade ES 300i is an inverter based MMA/Stick and LiveTIG machine with extreme power to weight ratio. The compact format makes it easy to carry and bring to any jobsite. Combined with high duty cycle and the ability to run the machine on long mains and welding cable makes this a superior welding machine for both on-and off site applications.The machine has an automatic input voltage sensor and can operate with any input voltage between 230 V and 480 V 3-phase.
300 A32.0 V @ 40 % Duty Cycle 250 A30.0 V @ 60 % Duty Cycle 200 A28.0 V @ 100 % Duty Cycle
TIG (GTAW) Welding Output
300 A22.0 V @ 60 % Duty Cycle 250 A20.0 V @ 100 % Duty Cycle
Setting Range
10-22 V (5-300 A) 20-32 V (5-300 A) 10-18 V (5-200 A) 20-28 V (5-200 A)
Current Range
5-300 A
Open Circuit Voltage
48 V 32 V
Power Factor at Maximum Current
0.96
Efficiency at Maximum Current
89 % 85 %
Fuse Slow
10 A 20 A (230 VDC)
Energy Save Mode
91 W
Supply Plug
CEE 16 A
Rated kVA
11.3 kVA
Enclosure Class
IP23
Application Class
S
Certification
CE
Dimensions, L x W x H
460 x 200 x 320 mm
Weight
15 kg
Accessories & Parts
Description
Product number
Shoulder Strap
0445197880
Electrode holder kit, Handy 300, OKC 50, 3 m
0700006902
Electrode holder kit, Handy 300, OKC 50, 5 m
0700006888
Return cable kit, 35 mm², OKC 50, 3 m
0700006903
ER 1 Remote Control incl. 5 m cable and 4-pin connector+
0445536880
5 m Replacement cable with 4-pin connector for ER 1 Remote Control
0445450880
MMA 3 Analogue Remote Control incl. 10 m cable and 6-pin connector *
0445870880
MMA 3 Analogue Remote Control incl. 25 m cable and 6-pin connector *
0445870881
10 m Replacement Cable for MMA 3 Analogue Remote Control *
0445204880
25 m Replacement Cable for MMA 3 Analogue Remote Control *
0445204881
Retrofit kit for MMA 3 Analogue Remote Control
0445840880
Extreme Portability for Any Job, Anywhere.
Tough jobs are your specialty. It’s why we created Renegade. Weighing in at 33-37 lbs. (depending on the model), it’s the most compact and lightweight welder in its class – making it the definition of a field machine. With three handles, it’s easy to grab and go, push, pull, or just throw it over your shoulder and work comfortably with the padded shoulder strap. You can even get to those hard-to-reach areas and tight spaces, welding with ease.
Rugged Power to Go, Even in Crazy Conditions.
Working in crazy conditions? Need a welder that can stand up to it all? Renegade offers the rugged power and durability you need. It runs 300 amps at 40% duty cycle with input welding cables up to 330 ft. – and even offers extreme voltage capabilities. Plus, it can withstand impact – so if you drop it, no problem – and temperatures up to 130ºF. Parts are also robust, reliable and simple to connect and disconnect…again and again.
Best-in-Class Weld Starts, Plus Hassle-Free Use.
Soft yet distinct starts. Easy cable control. Quick set-up with little or no training. Renegade offers all that and more, including a faster read on your arc than what most machines can deliver. This means better control, higher travel speed, more stability, and virtually no spatter in Stick Mode. You can also set parameters and read them from a distance, in any light, with the intuitive interface.
We’ve Got You Covered with TIG and Stick Capabilities.
Whether you’re TIG or Stick welding, Renegade helps you unleash your inner warrior. It offers two dynamic models: ES 300i for Stick and ET 300iP for HF TIG applications and Stick, which is available with and without a water cooler. In fact, in less than a minute, Renegade can go from a water-cooled system hooked up to a cart to an air-cooled portable machine – all without tools.
